Hardware Identification
å Screws are shown actual size. You may receive extra hardware with your unit.
CAM SCREW - 16
5
SMALL HIDDEN
CAM - 6
4
LARGE WOOD
DOWEL - 18
6
SMALL WOOD
DOWEL - 2
7
KNOB SET - 4
9
EXTENSION
RAIL - 2
1
EXTENSION
SLIDE - 2
2
L-WRENCH - 1
15
BLACK 1" MACHINE SCREW - 4
18
BLACK 1/2" PAN HEAD SCREW - 16
20
BLACK 1-3/8" FLAT HEAD SCREW - 4
17
HIDDEN CAM - 10
3
METAL PIN - 4
14
HINGE - 4
8
(EXTENSION SET SHOWN SEPARATED)
ADHESIVE TAPE - 2
12
Page 4 www.sauder.com 428244
BLACK 2-3/4" HEX HEAD SCREW - 8
16
BLACK 5/8" FLAT HEAD SCREW - 30
19
BLACK 1/2" FLAT HEAD SCREW - 6
21
APPLIQUE CARD - 2
13
11
BUMPER CARD - 1
22
BLACK 1" FLAT HEAD SCREW - 2
