Sauder Hammond 428244 - Page 8

Step 4
Page 8 www.sauder.com 428244
å
Insert ten LARGE WOOD DOWELS (6) into the exact
holes shown in the ENDS (B and C) and BRACE (F).
å
Insert two SMALL WOOD DOWELS (7) into the exact
holes shown in the DRAWER BRACE (M).
å
Fasten the WOOD BLOCK (Q) to the BRACE (F) exactly
as shown. Use two BLACK 1" FLAT HEAD SCREWS (22).
6
6
7
F
M
B
C
Surface with
HIDDEN CAMS
Q
BLACK 1" FLAT HEAD SCREW
(2 used in this step)
22
