Sauder Harbor View 403793 - Assembly Tools and Identification; Part Identification

Table of Contents Assembly Tools Required
Part Identifi cation
Hardware Identifi cation
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
A DOOR RIGHT END (1)
B DOOR LEFT END (1)
C DRAWER RIGHT END (1)
D DRAWER LEFT END (1)
E RIGHT UPRIGHT (1)
F LEFT UPRIGHT (1)
G3 TOP (1)
H2 SMALL TOP (1)
I MODESTY PANEL (2)
J BOTTOM (1)
K BACK (2)
L BRACE (2)
M DOOR (1)
N DRAWER FRONT (1)
S2 KEYBOARD UPRIGHT (2)
T KEYBOARD SHELF (1)
U SMALL DRAWER FRONT (2)
X BASE (2)
AA RIGHT MOLDING (1)
BB LEFT MOLDING (1)
D24 SMALL DRAWER RIGHT SIDE (2)
D25 SMALL DRAWER LEFT SIDE (2)
D28 DRAWER RIGHT SIDE (1)
D29 DRAWER LEFT SIDE (1)
D78 DRAWER BACK (1)
D109 SMALL DRAWER BACK (2)
D707 DRAWER BOTTOM (1)
D716 SMALL DRAWER BOTTOM (2)
2-3
4-5
6-36
37-40
41-44
45-46
47
Now you know
our ABCs.
Part Identifi cation
å While not all parts are labeled, some of the parts will have a label or an inked letter on the ede
to help distinuish similar parts from each other. Use this part identifi cation to help identify similar parts.
403793 www.sauder.com/servicesPae 2
Electric drill with 1/8" bit
(ONLY in indicated step)
