Sauder Harbor View 417586 - Product Identification and Assembly Tools; Assembly Tools Required; Part Identification

Part Identifi cation
Hardware Identifi cation
Assembly Steps
Troubleshooting
Français
Español
Safety
Warranty
2-3
4-5
6-55
56
57-64
65-72
73-74
75
Assembly Tools RequiredTable of Contents
Now you know
our ABCs.
Part Identifi cation
Electric drill with 1/8" bit
(ONLY in indicated step)
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Scissors
Masking Tape
A DOOR RIGHT END (1)
B DOOR LEFT END (1)
C DRAWER RIGHT END (1)
D DRAWER LEFT END (1)
D24 SMALL RIGHT DRAWER SIDE (2)
D25 SMALL LEFT DRAWER SIDE (2)
D28 RIGHT DRAWER SIDE (1)
D29 LEFT DRAWER SIDE (1)
D78 DRAWER BACK (1)
D109 SMALL DRAWER BACK (2)
D707 DRAWER BOTTOM (1)
D716 SMALL DRAWER BOTTOM (2)
E RIGHT UPRIGHT (1)
F LEFT UPRIGHT (1)
G3 TOP (1)
H3 SMALL TOP (1)
I MODESTY PANEL (2)
J BOTTOM (1)
K BACK (2)
L BRACE (2)
M DOOR (1)
N DRAWER FRONT (1)
O SMALL DRAWER FRONT (2)
P ADJUSTABLE SHELF (1)
Q2 KEYBOARD UPRIGHT (2)
U KEYBOARD SHELF (1)
X BASE (2)
AA RIGHT MOLDING (1)
BB LEFT MOLDING (1)
å While not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identifi cation to help identify similar parts.
417586 www.sauder.com/servicePage 2
