Fasten the LEFT UPRIGHT (F) to the RIGHT UPRIGHT (E).
Use two BLACK 1-7/8" FLAT HEAD SCREWS (2S).
Step 17
E
F
Edge with CAM DOWEL
BLACK 1-7/8" FLAT HEAD SCREW
(2 used in this step)
2S
Do not stand the unit upright without the
BACK fastened. The unit may collapse.
Caution
Surface with
HIDDEN CAM
Surface with
HIDDEN CAM
417586www.sauder.com/service
Page 23
