Step
å
Use a drill and a 1/8" drill bit to fi nish drilling the two holes
in the DRAWER LEFT END (D).
å
Fasten the other MODESTY PANEL (I) to the
DRAWER LEFT END (D). Use two BLACK 1-7/8" FLAT
HEAD SCREWS (2S).
å
Fasten an ANGLE BRACKET (5G) to the SMALL TOP (H3)
and MODESTY PANEL (I). Use two BLACK 9/16" LARGE
HEAD SCREWS (1S).
Step 24
H3
I
D
BLACK 9/16" LARGE HEAD SCREW
(2 used for the ANGLE BRACKET)
1S
5G
BLACK 1-7/8" FLAT HEAD SCREW
(2 used for the MODESTY PANEL)
2S
Use a 1/8" drill bit to fi nish drilling
these holes completely through.
417586 www.sauder.com/servicePage 30
DOOR ON LEFT AND
DRAWERS ON RIGHT
To Next Page
