Step 31
å
Use a drill and a 1/8" drill bit to fi nish drilling the two holes
in the DOOR LEFT END (B).
å
Fasten the other MODESTY PANEL (I) to the
DOOR LEFT END (B). Use two BLACK 1-7/8" FLAT
HEAD SCREWS (2S).
å
Fasten an ANGLE BRACKET (5G) to the SMALL TOP (H3)
and MODESTY PANEL (I). Use two BLACK 9/16" LARGE
HEAD SCREWS (1S).
A
B
BLACK 9/16" LARGE HEAD SCREW
(2 used for the ANGLE BRACKET)
1S
5G
BLACK 1-7/8" FLAT HEAD SCREW
(2 used for the MODESTY PANEL)
2S
Use a 1/8" drill bit to fi nish drilling
these holes completely through.
417586www.sauder.com/service
Page 37
DOOR ON RIGHT AND
DRAWERS ON LEFT
To Next Page
