Sauder Harbor View 417586 - Hardware Identification Guide

Hardware Identifi cation
å Screws are shown actual size. You may receive extra hardware with your unit.
GG
NUMBERED RIGHT
CABINET RAIL - 1
HH
NUMBERED LEFT
CABINET RAIL - 1
JJ
NUMBERED LEFT
DRAWER SLIDE - 1
II
NUMBERED RIGHT
DRAWER SLIDE - 1
FILE ROD - 2
8B
35DA
CABINET RIGHT - 2
35DB
CABINET LEFT - 2
35DC
DRAWER RIGHT - 2
35DD
DRAWER LEFT - 2
TIE PLATE - 2
41G
HIDDEN CAM - 18
1F
CAM DOWEL - 18
2F
HIDDEN
CONNECTOR - 4
9F
13H
HINGE - 2
ANGLE
BRACKET - 10
5G
10A
SLIDE CAM - 6
FILE GLIDE - 2
15B
KNOB - 1
5K
PULL - 3
98K
40AW
CABINET RIGHT - 1
40AX
CABINET LEFT - 1
40AY
DRAWER RIGHT - 1
40AZ
DRAWER LEFT - 1
METAL
BRACKET - 4
2G
417586 www.sauder.com/servicePage 4
