Sauder Harbor View 417587 - Product Identification and Preparation; Assembly Tools and Parts

Table of Contents Assembly Tools Required
Part Identifi cation
Hardware Identifi cation
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Skip the power trip.
This time.
2-3
4
5-22
23-25
26-28
29-30
31
417587 www.sauder.com/servicesPage 2
å While not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identifi cation to help identify similar parts.
Now you know
our ABCs.
Part Identifi cation
A RIGHT END (1)
B LEFT END (1)
C RIGHT UPRIGHT (1)
D LEFT UPRIGHT (1)
E TOP (1)
F SHELF (1)
G BOTTOM (2)
H LARGE BACK (1)
I BACK (2)
J SMALL BACK (2)
K DOOR (2)
L VALANCE (1)
M MOLDING (2)
