Step 1
Look for this icon. It means a
video assembly tip is available at
www.sauder.com/services/tips
å
Assemble your unit on a carpeted fl oor or on the empty
carton to avoid scratching your unit or the fl oor.
å
Push sixteen HIDDEN CAMS (1F) into the ENDS (A and B),
UPRIGHTS (C and D), and BOTTOMS (G). Then, insert the
metal end of a CAM DOWEL (2F) into each HIDDEN CAM.
417587www.sauder.com/services
Page 5
Arrow
1F
2F
(16 used)
Arrow
1F
2F
Insert the metal end of the CAM
DOWEL into the HIDDEN CAM.
Arrow
Do not tighten the HIDDEN CAMS in this step.
