Fasten the UPRIGHTS (C and D) to the BOTTOMS (G).
Tighten four HIDDEN CAMS.
Step 5
417587www.sauder.com/services
Page 9
Arrow
Minimum
190 degrees
Maximum
210 degrees
G
G
D
C
Surface without
HIDDEN CAMS
Surface with
HIDDEN CAMS
Finished edge
