Sauder Lateral File - Page 24

Step 20
å
Flip the drawer over onto the left DRAWER SIDE (D225).
å
Diaram 1. Insert the tabs on a DRAWER STOP (20G) into the slots in a EXTENSION SLIDE (R). You may need to insert
one tab fi rst, then the other.
å
Diaram 2. Visually check that the DRAWER STOP (20G) is seated in the EXTENSION SLIDE (R).
å
Diaram 3. If the DRAWER STOP is not seated, use your hammer to ently tap the SLIDE until the tabs are properly seated
in the slots.
å
Now, fasten the EXTENSION SLIDE (R) to the riht DRAWER SIDE (D225). Use two GOLD 5/16" FLAT HEAD SCREWS (3S)
throuh holes #2 and #4.
å
Repeat this step for the other drawer.
20G
R
2.
3.
Post
4
1
2
3
GOLD 5/16" FLAT HEAD SCREW
(4 used in this step)
3S
1.
These tabs must
insert into the slots.
Open end
Seated
Slot
D225
20G
R
R
420040 www.sauder.com/servicesPae 24
D225
