Fasten a LOCK (16J) to the UPPER DRAWER FRONT (L).
Use two SILVER 1/2" FLAT HEAD SCREWS (78S).
å
NOTE: Position the LOCK exactly as shown.
å
Push a LOCK COVER (10J) over the key extension of the
LOCK (16J) until it is even with the front surface.
å
Repeat this step for the other drawer.
Step 22
10J
L
16J
SILVER 1/2" FLAT HEAD SCREW
(4 used in this step)
78S
Key extension
420040 www.sauder.com/servicesPae 26
L
If you're doin this to
help a friend, don't
leave without a bite.
