Sauder Nova Loft 423720 - Hardware Identification Guide

Hardware Identifi cation
å Screws are shown actual size. You may receive extra hardware with your unit.
BLACK 5/8" FLAT HEAD SCREW - 13
15
BLACK 7/8" HEX HEAD SCREW - 8
13
BLACK 1-3/4" FLAT HEAD SCREW - 4
11
BLACK 1-9/16" FLAT HEAD SCREW - 24
12
L-WRENCH - 1
8
PULL - 3
7
FILE GLIDE - 2
9
FILE HANGER - 2
10
(EXTENSION SET SHOWN SEPARATED)
EXTENSION SLIDE - 2
2
EXTENSION RAIL - 2
1
LEFT DRAWER
SLIDE - 2
6
RIGHT DRAWER
SLIDE - 2
5
LEFT CABINET
RAIL - 2
4
RIGHT CABINET
RAIL - 2
3
BLACK 13/16" MACHINE SCREW - 6
14
BLACK 1/2" FLAT HEAD SCREW - 36
16
Page 4 www.sauder.com/service 423720
BLACK 3/8" MACHINE SCREW - 34
17
