Fasten four HALF DISKS (U) to four PLINTHS (T). Use four SILVER
1-1/8" FLAT HEAD SCREWS (10S).
å
Fasten ten ANGLE BRACKETS (27G) to the OUTER ENDS (A and B).
Use ten BLACK 9/16" LARGE HEAD SCREWS (1S).
å
NOTE: Be sure the edes of the ANGLE BRACKETS are even with
the edes of the ENDS.
å
Fasten the PLINTHS (T) and VERTICAL MOLDINGS (M26) to the
OUTER ENDS (A and B). Use ten BLACK 9/16" LARGE
HEAD SCREWS (1S).
Step 2
412015www.sauder.com/services
Pae 7
The larer
hole should
be facin up.
T
T
T
T
T
T
U
U
U
U
A
B
Surface with
TWIST-LOCK
®
FASTENERS
Surface with
TWIST-LOCK
®
FASTENERS
Use the holes below the roove in
the VERTICAL MOLDING (M26).
Use the holes
below the roove
in the VERTICAL
MOLDING (M26).
27G
27G
The VERTICAL
MOLDINGS should
be centered over
the HALF DISKS.
The VERTICAL MOLDINGS should
be centered over the HALF DISKS.
(10 used)
SILVER 1-1/8" FLAT HEAD SCREW
(4 used for the HALF DISKS)
10S
BLACK 9/16" LARGE HEAD SCREW
(20 used for the ANGLE BRACKETS)
1S
M26
M26
Use the lower two
holes in the PLINTH.
