To make adjustments to the drawer, loosen SCREW #3 in the SLIDES a 1/4 turn, then turn the cam clockwise or
counter-clockwise. Notice how the drawer raises or lowers as you turn the cam. By adjusting the drawer this way, it
will help the DRAWER FRONT line up better when closed. Tighten the SCREWS when fi nished with adjustments.
å
NOTE: Please read the back pages of the instruction booklet for important safety information.
å
This completes assembly. Clean with a damp cloth. Wipe dry.
Step 27
425014 www.sauder.com/servicePage 32
CamThe higher the screw in the oblong hole,
the higher your drawer front will be. The
lower the screw, the lower the drawer front.
Loosen screw #3 a 1/4 turn, turn the cam a 1/4 turn
maximum in both the clockwise and counter-clockwise
directions to make adjustments, and then tighten screw #3.
And to celebrate, why not share your success story at sauder.com or
