Step 4
425014www.sauder.com/service
Page 9
å
First, fi ll the holes in the LEGS (U and V) 1/4 to 1/2 full with
GLUE (54M). Then, insert the WOOD DOWELS (15F) into the
holes. Wipe away the excess GLUE.
å
Now, fi ll the holes in the UPRIGHT (C) and LEFT BRACE (O) 1/4
to 1/2 full with GLUE.
å
Fasten the LEGS (U and V) to the UPRIGHT (C) and LEFT
BRACE (O). Tighten six HIDDEN CAMS.
å
NOTE: Be sure the WOOD DOWELS in the LEGS insert into the
UPRIGHT and LEFT BRACE. Wipe away the excess GLUE.
C
O
U
V
Fill the holes 1/4 to 1/2 full with GLUE.
Inspect the parts thoroughly before
assembling. Disassembly of glued
parts is extremely di cult.
Caution
!
54M
15F
1
2
Surface
with
HIDDEN
CAMS
These surfaces
should be even.
Edge with
CAM DOWELS
15F
Surface
with
HIDDEN
CAMS
To Next Page
