Sauder WHISKER - Page 12

å
Flip the UPRIGHT (G) over.
å
Fasten an EXTENSION RAIL (1) to the UPRIGHT (G). Use three 1/2" FLAT HEAD SCREWS (16).
å
NOTE: For each EXTENSION RAIL, turn a SCREW into the 1st hole shown in the diagram.
Then, slide the inner cartridge of the EXTENSION RAIL in to nd the other holes that line up
with the holes in the UPRIGHT. Turn a SCREW into each hole.
G
1
1
st
Open end
1/2" FLAT HEAD SCREW
(3 used in this step)
16
1
Open end
1
st
429610
whiskersupport.com
Page 12
STEP 7
