Port Configuration
By default, all ports are in access mode for VLAN 1. If you are not utilizing VLANs in your environment, you will not
need to configure the VLAN settings for the switch ports further. We recommend isolating backplane ports for Scale
Computing equipment to a VLAN other than 1 using access mode.
Switchport Access Mode
Access mode allows only one VLAN to be configured for a switch port. Use this mode when connecting an end
device that is unaware of VLANs, such as the Scale Computing node backplane ports.
(config)# interface ethernet 1/1
(config interface ethernet 1/1)# switchport mode access
(config interface ethernet 1/1)# switchport access vlan 10
Switchport Hybrid Mode
Hybrid mode is used when an interface needs to carry multiple VLANs, such as the Scale Computing LAN ports. If
your VMs need access to specific VLANs other than what the Scale Computing node itself resides upon, you will
need to tag those VLANs. In this example, the Scale Computing appliance is being managed on VLAN 5. The
management interface is unaware of VLANs and thus needs to be untagged traffic. Any additional VLANs need to be
added to the list of allowed-vlan.
(config)# interface ethernet 1/1
(config interface ethernet 1/1)# switchport mode hybrid
(config interface ethernet 1/1)# switchport access vlan 5
(config interface ethernet 1/1)# switchport hybrid allowed-vlan add 10
Configure Spanning Tree
Ensure spanning tree is enabled:
(config)# spanning-tree
(config)# spanning-tree mode rpvst
NOTE
The number of VLANs supported by RPVST is 128.
Set ports connected to Scale Computing equipment to edge mode:
(config)# interface ethernet 1/1
(config interface ethernet 1/1)# spanning-tree port type edge
©
Scale Computing 2018 9
