9
©2011 Scaletron Industries Ltd., Plumsteadville, PA Scaletron, Scaletron Sets the Standard In Corrosion Resistance, Model 1020-1, 1020-2, Model 1099, Model 2305, Model
2306, Model 2307, Model 2308, Model 2310, Model 2330, Model 2350, Model 2352, Model 2353, Model 3001, Model 3002, Model 3003, Model 3004, Model 3005, Model 3006,
Model 3050-1, Model 3050-2, Model 4000SS, Model 4010, Model 4020, Model 4021, Model 4030, Model 4040, Model 4040IBC, Model 4041, Model 4042, and Model 4042WB
are trademarks of Scaletron Industries Ltd. Total Electronic System is a service mark of Scaletron Industries Ltd.
PRINTED IN THE U.S.A. MAY 2011.
keypad. (It is wise to allow the contents to settle if possible, for 15
minutes before pressing enter.) When ready, press enter. The LCD will
ask you: Are you sure? You will press ENTER for yes. This is now
complete. Press ESC one time to see the Net Weight screen, which will
now reflect the Net weight of the cylinders/tanks you have reloaded.
(Example: Two Ton bases are connected to channel one. You are
loading on a new Ton cylinder with 2000 lbs of contents, and you have
1150 lbs. of contents in the second Ton cylinder. (You replace the empty
tank with a full one, and load on the partially full tank as you proceed
through the “LOAD TANK (NET) menu.) When the scale prompts to
remove empties, you must clear off all bases. Then you are prompted to
load new cylinders. Both cylinders are re-loaded, and you press enter.
The next screen asks you to enter the net weight. ADD the NET weights
of both cylinders you will have re-loaded, and type that number in using
the keypad. Your combined net weight is: 3150. You type in 3-1-5-0- and
press ENTER. The screen will ask: Are you sure? And you will press
ENTER to say Yes. The screen will return to the head of the sub menu.
At this time you know that you have completed this function. Press the
ESC key to return to the main, “Net Weight” screen. Begin using the
contents.)
Load a Tank (Tare):
From main screen (NET WEIGHT), press Display Select one time. You
will see “Load Tank (Tare)” on the LCD. Press ENTER to gain access to
this Sub Menu. Your LCD will read “Enter Scale #1” with two up/down
arrows. If you have only one channel activated, you will not change this
screen by pressing the Menu ab keys. If you have more than one
channel activated, you will be able to scroll through the different “scales”,
or channels, that are active. Choose the “scale” or channel you wish to
reload by pressing the ENTER key. Your LCD will read, “REMOVE
EMPTY AND PRESS ENTER”. At this time, you must remove all
cylinders/tanks that are on bases hooked to this channel before pressing
anything! When scale base(s) are empty, proceed by pressing ENTER.
Your LCD will read, “LOAD TANK AND PRESS ENTER”. You must load
all cylinders on at this time (even if some are not full) before pressing
anything. Please note: if you have a partially used cylinder that you are
reloading on a base hooked to this channel, you must know the TARE
weight (the weight of the cylinder/tank) and add the Tare Weights of all
cylinders/tanks that are connected to this channel. Add the Tare weight of
all cylinders/tanks on this channel and type that number in, using the
keypad. (It is wise to allow the contents to settle if possible, for 15
minutes before pressing enter.) When ready, press enter. The LCD will
ask you: Are you sure? You will press ENTER for yes. This is now
