© 2004. Scaletron Industries Ltd. Plumsteadville, PA Scaletron. Scaletron Sets The Standard In Corrosion Resistance. Model 1099, Model 2310,
Model 2330, Model 2350, Model 2352, Model 2353, Model 3001, Model 3002, Model 3003, Model 3004, Model 3005, Model 3006, Model 4010, Model
4020, Model 4021, Model 4030, Model 4040, Model 4041, Model 5305, and Pro-Gram Guide are trademarks of Scaletron Industries Ltd. Total
Electronic System is a service mark of Scaletron Industries Ltd. All Rights Reserved. PRINTED IN U.S.A. Oct 2004.
These instructions generally describe the installation, operation, and maintenance of subject
equipment. The manufacturer reserves the right to make engineering refinements that have not been
described herein. Should any questions arise that may not be answered specifically by these
instructions, they should be directed to SCALETRON INDUSTRIES, LTD. OR OUR SALES AGENT
for a response.
All possible precautions were taken in packaging each piece of equipment to prevent shipping
damage. Carefully inspect each item and report damages immediately. Report damage claims to
shipping agent involved for equipment shipped F.O.B. job site. Do not install any damaged
equipment.
All instructions given on any labels, or attached tags, should be followed. Carefully inspect all
packing material before discarding to prevent the loss of accessories, mounting hardware, spare
parts, or instructions.
TABLE OF CONTENTS PAGE
I. GENERAL DESCRIPTION................................................................……………………………..1
II. SPECIFICATIONS..................................................……………………………………………..1 - 2
III. ASSEMBLY AND START-UP INSTRUCTIONS………….............………………….…………….2
IV. GENERAL USE INSTRUCTIONS……………….................................……………………......2 - 3
V. CALIBRATION PROCEDURE......................................................... …………..…………….…...3
VI. TROUBLESHOOTING.......................................... ……….………………………….………….….4
VII. BOARD DIAGRAM & 4-20mA CONNECTION DIAGRAM…………………………………….5 - 6
I. General Description:
The Model 2350™ Digital Dual Cylinder Scale is designed for weighing cylinders 11 ¾ inches
in diameter and smaller with a maximum net weight of 199.9 lbs. and a maximum tare weight
of 150 lbs. The low profile design of the platform (1 ½ ”) allows for safe and easy loading of
cylinders. A pedestal, crossbar, and chains are provided to secure cylinders in place. The
printed circuit board contains a power supply section and two separate tare and span controls,
one for each disc. A 4-20 mA output signal is provided for each display. The weigh meter
electronics are housed in a NEMA 4X enclosure for mounting on top of the pedestal, or
remotely.
STANDARD PARTS AVAILABLE OPTIONS
1 Base Assembly A. Remote mounting of standard enclosure
1 Pedestal B. Load Cell Cable
1 Crossbar C. Low Level relay contact
1 Weigh meter
1 Power cord
1 Bag of Hardware
1 Technical Manual
2 Chains
1 “U” Bolt
II. Specifications:
Display: LCD 3 ½ digit with minus sign, liquid crystal display, 0.5” high, seven segment
Resolution: Single cylinder 199.9 lbs. x 0.1 lbs. (90 kg. x 0.1 kg.)
Load Cell Excitation: 12 VDC Power 6 Cells
Zero Adjustment: Internal potentiometer, external tare knobs
Overload: Blanks with “1” displayed at far left of display
