TechnicalInstructions TSSeries
DocumentNo.TS‐6500
Page4SCCInc.
ProductPartNumbers(continued)
Table1:TS…ProtocolConverterPartNumbers
FIELDPort HOSTPort EthernetSwitch
PartNumber
Profinet
Profibus
RS‐232
RS‐485
None
5‐port
8‐port
13‐port
16‐port
TS‐PN2‐X x x x

TS‐PN4‐X x x x

TS‐PN4‐3 x x x

TS‐PN4‐6 x x x

TS‐PN4‐9 x x
x
TS‐PN4‐12 x x
x
TS‐PB2‐X x x x

TS‐PB4‐X x x x

TS‐PB4‐3 x x x

TS‐PB4‐6 x x x

TS‐PB4‐9 xx
x
TS‐PB4‐12 xx
x
