Schacht Flatiron - Page 2

-2-
FLATIRON SPINNING WHEEL
Assembly InstructIons
PARTS
1X front frame
1X rear frame
1X crank--and-footmen assembly
1X rear maiden
1X rear maiden front guide
1X rear maiden back guide
1X MOA assembly
1X front maiden assembly
1X drive wheel assembly
1X bar assembly
1X short treadle
1X long treadle
1X wide leg brace
1X narrow leg brace
1X yer assembly
3X travel bobbins
1X fast whorl
1X medium whorl
1X third hand assembly
8X parts bags
TOOLS NEEDED
#2 Phillips screwdriver
slotted (at) screwdriver
We have posted a video of The Flatiron being assembled
according to these instructions on our YouTube channel
https://www.youtube.com/user/schachtspindle
wide
leg brace
yer
assembly
travel
bobbins
short
treadle
long
treadle
narrow
leg brace
treadle bar
assembly
fast
whorl
medium
whorl
MOA
assembly
drive wheel
assembly
rear
maiden
crank-and-
footmen
assembly
rear frame
front
frame
front maiden
assembly
rear maiden
back guide
third hand
assembly
rear maiden
front guide
