Schaudt CV 304 - Connect the Pump; Faults

Instruction manual caravan distributor CV 304 with switch panel
4
Stand: 24.06.2016 8120065 BA / EN
" Press rocker switch (12V main switch) so that it is briefly in the ”I” po-
sition or touch the sensor
(LT151).
F The power supply is connected to all the consumers.
F Supply is provided via the battery of the towing vehicle when connec-
ted up. Circuit 5 (awning light) is disabled so that it cannot be swit-
ched on whilst the vehicle is moving (a legal regulation in some coun-
tries). For mains or battery operation, power is supplied from the
caravan battery (also circuit 5).
" Refer to the documentation of the vehicle manufacturer for more details
about and operation of the 230V power cut-out.
" Press 12V main switch so that it is briefly in the ”O” position or touch
the sensor
(LT151).
3.2 Connec t the pum p
For the pump to be switched on, the 12V supply voltage must first be swit-
ched on (see Section 3.1 for the main supply).
" Move the switch with the pump symbol upwards or touch the sensor
(LT151).
The supply voltage for the water pump is enabled:
F The pump may switch on briefly (e.g. in a pressure system).
F In other systems, the pump is enabled by the water tap contacts.
" Move the switch with the pump symbol downwards or touch the sen-
sor (LT151)..
3.3 Faults
A fault in the power supply system is usually caused by a blown fuse.
Please contact our customer service team if you cannot rectify the fault
using the following table.
If this is not possible, e.g. if you are abroad, you can have the caravan distri-
butor repaired at a specialist workshop. In this case, you must ensure that
the warranty is not invalidated by incorrect repairs being carried out.
Schaudt GmbH will not accept any liability for damage resulting from such
repairs.
Fault Possible cause Remedy
12V supply does not work 12V main switch is off 12V main switch must be
1
2
V
s
u
p
p
l
y
d
o
e
s
n
o
t
w
o
r
k
in the living area
1
2
V
m
a
i
n
s
w
i
t
c
h
i
s
o
f
f
1
2
V
m
a
i
n
s
w
i
t
c
h
m
u
s
t
b
e
switched on
No supply voltage Check the battery or
mains c onnection
Battery (caravan) dischar-
ged
Check the battery and re-
place/charge as required
Vehicle battery discharged
p
g
q
Defective fuse or wiring Check fuse and wiring
Blown vehicle fuse Check the fuse and re-
place it if required
Caravan distributor defec-
tive
Call customer service
Switching on
Switching off
Switching on
Switching off
Flat vehicle fuses
