Operating Instruction Manual of Energy Management System
EBL 208 S, Art.-No. 911.470 Seite 3 / 7
note: operating instruction manual is intended for the owner and has to come with the EBL
Schaudt GmbH - Elektrotechnik & App.-bau - 88677 Markdorf - Germany 13.12.2001
2. Safety Information
* The electrical installation of the motorhome has to be in accordance with current DIN-, VDE- and
ISO-regulations. Alterations will endanger the safety of persons and the vehicle.
Due to the above mentioned regulations and safety rules, alterations are therefore prohibited.
* The connection of the EBL to the mains supply has to be in accordance to national installation rules.
* The energy system EBL 208 S must not be modified.
* The connection of the energy system has to be done by qualified personnel only and must be
conform to specifications mentioned in this operating instruction manual:
see instruction manual section 4.2 'Installation'
section 5 'Electrical Installation'
and in enclosure schematic diagram of EBL 208 S
* In the following text special notice should be paid to the signs shown below:
CAUTION !
Electrical current hazard warning.
CAUTION !
General hazard warning.
3. Operating Instructions
3.1 Controls
12V fuses Pluggable FK2 automotive fuses
battery-type selector switch The mains plug of the energy system has to be taken off prior to
actuating the battery-type selector switch on the frontside of the device.
Eg Seperate vehicle from mains supply.
Before power-up of the energy system this switch has to be selected
according to the type of battery used (lead-acid or lead-gel).
The switch ensures an optimum charge of the connected battery type.
To actuate use a thin tool (eg a pencil tip).
Caution !
An incorrect selected battery-type switch may damage the batteries and there may be an
explosion-hazard caused by detonating gas.
battery cut-off switch The battery cut-off switch 'Battery' seperates the control and switch board
and the anti-freeze valve of the heater system from the living-area battery,
to inhibit stand-by currents while vehicle is non-operative.
See detail 6.2 'Shut-Down'
Attention !
Please note if anti-freeze valve is deactivated by the battery cut-off switch 'Battery', in
position 'off', the safety-valve of the boiler opens automatically.
note: To reactivate all load after being cut-off by battery cut-off switch 'Battery' or after a battery
change, please actuate 12V main switch on the instrument panel.
12V main switch With push-button switch '12V EIN/AUS' all load, except automatic step
on instrument panel and AES-refrigerator, is being switched on and off.
Please refer to instruction manual of the instrument panel.
