Instruction Manual Electrobloc EBL 269
Battery selector switch
The switching option provided by the battery selector switch ensures optimum
charging of the two different types of battery, lead acid and lead gel. The
switch must be set to the correct battery type: lead acid or lead gel.
Use a thin object (e.g. a ballpoint pen cartridge) to move the battery selector
switch.
Set lead gel battery: Set the battery selector switch to "Blei-Gel" (lead gel).
Set lead acid battery: Set the battery selector switch to "Blei-Säure" (lead
acid).
12 V main switch (on the
control and switch panel)
The 12 V main switch on the control and switch panel switches all consumers
and the panel on and off.
Exceptions:
●
Frost protection valve
●
Heater
●
Step
●
AES/compressor refrigerator
●
For EBL 269 and EBL 269 A: Circuit 1, awning light
●
For EBL 269-2 and EBL 269-2 A: Circuit 4, circuit 5
For more information, see the instruction manual of the control and switch
panel.
6.2 Additional functions
Automatic switch function
for AES/compressor
refrigerator
This relay supplies the AES/compressor refrigerator with power from the
starter battery when the vehicle engine is running and the D+ connection is
live. An AES/compressor refrigerator is powered by the living area battery
when the vehicle engine is switched off.
Automatic switch function
for absorber refrigerator
This relay supplies the absorber refrigerator with power from the starter bat-
tery when the vehicle engine is running and the D+ connection is live.
Mains charging of starter
battery
This feature provides an automatic float charge for the starter battery at up to
2 A when the 230 V mains is connected to the Electrobloc.
▲ Danger of explosion from formation of detonating gas due to an incor-
rectly set battery selector switch, defective batteries, defective Electrob-
loc or an excessively high battery working temperature (more than
30 °C).
▲ An incorrectly set battery selector switch damages the living area battery.
▲ Disconnect the Electrobloc from the mains before adjusting the battery
selector switch.
