Schaudt Electroblock EBL 220-4 A - Changing the Battery

Electroblock EBL 220-4 A / EBL 220-4 with OVP instruction manual
4
Issued: 21.06.2010 811.592 BA / EN
The 12 V main switch (see the instruction manual for the associated control
and switch panel) switches all consumers and the control and switch panel
on and off.
Exceptions:
F Frost protection valve
F Heater
F Step
F Gas alarm/waste water valve
F Power circuit 4
F W aste-water tank heating
F Fold-away bed
F Awning light
F Awning
F Aerial
F AES/compressor refrigerator
F Fridge controller
For more information, see the DT/LT ... control and switch panel instruction
manual.
Y ATTENTION!
The self-resetting fuse can trip!
Overcurrent cut-out:
F Only press the step switch briefly.
³ Wait approx. 1 minute before pressing the step switch again so that the
fuse can reset itself.
Y ATTENTION!
Battery buffer function missing!
The connected devices will be damaged:
F Never run the solar charger without a battery being connected.
3.2 Changing the battery
Y ATTENTION!
Wrong battery type or incorrectly connected battery!
Will damage the battery or the devices connected up to the Electroblock:
F Batteries shall only be changed by qualified personnel.
F Follow the instructions of the battery manufacturer.
F The Electroblock is to be used solely for connecting the 12 V power
supply to 6-cell lead-gel or lead-acid batteries. Never use unapproved
types of battery (e.g. NiMH batteries).
Y Only batteries of the same type and capacity should normally be used,
i.e. same as those installed by the manufacturer.
Y You can change over from lead-acid to lead-gel batteries. You cannot
change over from lead-gel to lead-acid batteries! Your vehicle manufactu-
rer will provide you with information about this.
Step switch
Solar charger operation
