Schaudt LT452 - Page 12

Operating Instructions Operator and control panel LT 45X
12
Date: 29.05.2020 9310330 BA / EN
Appendix
A Block diagram/wiring diag ram
Circuit board
1
2
3
4
5
6
1
2
3
4
5
1
2
3
Full
3/4
1/2
1/4
Base
n.c.
Full
3/4
1/2
1/4
Base
MicroFit ST2,
e.g. Molex 3.0
No. 43645-0600
Rear
Top
MicroFit ST3,
e.g. Molex 3.0
No. 43645-0500
MicroFit ST 1
e.g. Molex 3.0
No. 43025-1000
12 V -- OFF
12 V -- ON
12 V -- Check
Mains
-- Sensor WB
W aste water tank
W ater tank
+ Sensor WB
SB
Pump
Light
AUX
4
5
6
7
8
9
10
B Customer service
Schaudt GmbH, Elektrotechnik & Apparatebau
Planckstraße 8
88677 Markdorf, Germany
Phone: +49 7544 9577-16
Email: kundendienst@schaudt-gmbh.de
Web: www.schaudt-gmbh.de
Returning a faulty device:
" Complete and enclose the fault report, see Appendix C.
" Send it to the addressee (free delivery).
Customer service
Send in device
