Operating Instructions Operator and control panel LT 45X
2
Date: 29.05.2020 9310330 BA / EN
1 Introduction
This instruction manual contains important information for the safe operation
of equipment supplied by Schaudt.
The operating instructions should always be kept in the vehicle.
Y ATTENTION!
Failure to comply with the sign may result in damage to equipment or other
connected loads.
LT 45X control panels differ as regards their configurations and the depiction
of symbols.
Y This documentation covers all LT 45X control panels. The following table
provides an overview of the configuration features.
Model
Front panel
12 V ON/OFF
Mains indicator
Voltage display
Leisure area battery
Voltage display
Starter battery
Fill level display
Water tank
Fill level display
W aste water tank
Pump switch
Light switch
AUX switch
LT450 X X X X X X X X X
LT451 X X X X X X
LT452 X X X X X X X
Configur at ion
