Operating Instructions Operator and control panel LT 45X
9
Date: 29.05.2020
9310330 BA / EN
The following table shows the correct interpretation of the off-load voltage
displayed. The values specified are guidelines for gel batteries.
Values for off- load voltage Charge state of the battery
12,0 V or lower Discharged or totally discharged
12,2V Approx. 25%
12,7V Approx. 50%
More than 12.7 V Full
3.5.2 Starter battery
" Touch the sensor for Check starter battery voltage.
The voltage of the starter battery is displayed.
3.6 Checking tank levels
" Touch Check tank level sensor:
-- W a t e r o r
-- Waste water
F The level of the relevant tank is displayed:
-- Water: 100%, 75%, 50%, 25%;
The tank is empty if the 25% LED flashes.
-- Waste water: 100%, 75%, 50%, 25%
