INDEX HEX VALUE TYPE INFORMATIONS DÉTAIL DE LA TRAME
1265 0x4F1 Humidity (PGN 130313) NMEA2000 gateway Cf NMEA standards for data description
1266 0x4F2 Salinity Station Data (PGN
130321)
NMEA2000 gateway Cf NMEA standards for data description
1267 0x4F3 Current Station Data (PGN
130322)
NMEA2000 gateway Cf NMEA standards for data description
1268 0x4F4 Meteorological Station Data
(PGN 130323)
NMEA2000 gateway Cf NMEA standards for data description
1269 0x4F5 Direction Data (PGN 130577) NMEA2000 gateway Cf NMEA standards for data description
1270 0x4F6 Vessel Speed Components
(PGN 130578)
NMEA2000 gateway Cf NMEA standards for data description
1271 0x4F7 System time (PGN 126992) NMEA2000 gateway Cf NMEA standards for data description
1272 0x4F8 Proprietary (PGN 65293) NMEA2000 gateway Cf NMEA standards for data description
1273 0x4F9 Proprietary (PGN 61184) NMEA2000 gateway Cf NMEA standards for data description
... ... 0x500 => 0x600 : libre
1537 0x601 Venus description NMEA2000 - Victron
gateway
Data(1..4) = Refer to register 0x0100
from VE.Can registers
1538 0x602 Battery #1 NMEA2000 - Victron
gateway
Data(0..1) = Service battery voltage in
0.01V [+/- 327.64] V
Data(2..3) = Current Service battery
current in 0.1A [+/- 3276.4] A
Data(4) = State of charge [0 : 252] %
Data(5..6) = Remaining time [0 : 65532]
minutes
Data(7) = Dummy 0xff
1539 0x603 Battery #2 NMEA2000 - Victron
gateway
Data(0..1) = Battery temperature
[0:655.32]°K
Data(2..5) = Energie consommée en
0.1A.h
Data(6..7) = Dummy 0xff
1540 0x604 MPPT NMEA2000 - Victron
gateway
Data(0..1) = Charger output current in
0.1A [+/- 3276.4] A
Data(2..5) = User yield 0.01kW.h (regis-
ter 0xEDDC of MPPT resetable by user)
Data(6..7) = Dummy 0xff
1541 0x605 Multiplus : Charger AC In 1 NMEA2000 - Victron
gateway
Data(0..1) = RMS Voltage AC Input 1
Line A to line B [0:64255] V (1V/bit)
Data(2..3) = RMS Voltage AC Input 1
Line A to Neutral [0:64255] V (1V/bit)
Data(4..5) = RMS Current AC Input 1 [0 :
64255] A (1A/bit)
Data(6..7) = Frequency [0 : 501.99] Hz
