INDEX HEX VALUE TYPE INFORMATIONS DÉTAIL DE LA TRAME
1542 0x606 Multiplus : Charger AC In 2 NMEA2000 - Victron
gateway
Data(0..1) = RMS Voltage AC Input 1
Line A to line B [0:64255] V (1V/bit)
Data(2..3) = RMS Voltage AC Input 1
Line A to Neutral [0:64255] V (1V/bit)
Data(4..5) = RMS Current AC Input 1 [0 :
64255] A (1A/bit)
Data(6..7) = Frequency [0 : 501.99] Hz
1543 0x607 Multiplus : DC Current NMEA2000 - Victron
gateway
Data(0..1) = Charger DC Current [+/-
3276.4] A
Data(2..3) = Inverter DC Current [+/-
3276.4] A
Data(4..7) = Dummy 0xff
1544 0x608 Multiplus : Inverter AC output NMEA2000 - Victron
gateway
Data(0..1) = RMS Voltage AC output
Line A to Neutral [0:64255] V (1V/bit)
Data(2..3) = RMS Current AC output [0 :
64255] A (1A/bit)
Data(4..5) = Frequency [0 : 501.99] Hz
Data(6..7) = Dummy 0xff
1545 0x609 Multiplus : status NMEA2000 - Victron
gateway
Data(0) = Mode
1 => Charger only
2 => Inverter only
3 => ON
4 => OFF"
Data(1..2) = AC In1 current limit in 0.1A
Data(3..4) = AC In2 current limit in 0.1A
Data(5..7) = Dummy 0xff
1546 0x60A Multiplus : set mode NMEA2000 - Victron
gateway
Data(0) = Mode
1 => Charger only
2 => Inverter only
3 => ON
4 => OFF"
Data(2..7) = Dummy 0xff
1547 0x60B Multiplus : set AC current limit NMEA2000 - Victron
gateway
Data(0..1) = AC In1 current limit in 0.1A
Data(2..3) = AC In2 current limit in 0.1A
Data(4..7) = Dummy 0xff
1548 0x60C Inverter Phoenix : AC Output NMEA2000 - Victron
gateway Data(0..1) = RMS Voltage AC output
Line A to Neutral [0:64255] V (1V/bit)
Data(2..3) = RMS Current AC output [0 :
64255] A (1A/bit)
Data(4..5) = Frequency [0 : 501.99] Hz
Data(6..7) = Dummy 0xff
1549 0x60D Inverter Phoenix : status NMEA2000 - Victron
gateway
Data(0) = Mode
3 => ON
4 => OFF"
Data(1..2) = Current in 0.1A
Data(3..7) = Dummy 0xff
1550 0x60E Inverter Phoenix : set mode NMEA2000 - Victron
gateway
Data(0) = Mode
3 => ON
4 => OFF"
Data(1..7) = Dummy 0xff
