P. 9
L’innovation française depuis 1965
INDEX HEX VALUE TYPE INFORMATIONS DÉTAIL DE LA TRAME
1551 0x606 Multiplus : Charger AC In 2 NMEA2000 - Victron
gateway
Data(0) = NMEA address of Battery
device
Data(1) = NMEA address of MPPT
device
Data(2) = NMEA address of Battery
charger (eg : Multiplus charger)
Data(3) = NMEA address of Ship mains
device (eg : Multiplus inverter)
Data(4) = NMEA address of Auxiliary
mains (eg : Phoenix inverter)
Data(5) = NMEA address of Auxiliary
charger(eg : Phoenix charger)
... ... 0x610 => 0x700 : Réservé
pour Victron
1792 0x700 Device list - Request with RTR
bit
Passerelle NMEA2000 -
Fusion
Data(0) = Fusion device 1's address
Data(1) = Fusion device 2's address
Data(2) = Fusion device 3's address
Data(3) = Fusion device 4's address
Data(4) = Fusion device 5's address
Data(5) = Fusion device 6's address
Data(6) = Fusion device 7's address
Data(7) = Fusion device 8's address
If more than 8 devices, value=254
1793 0x701 Set current device Passerelle NMEA2000 -
Fusion
Data(0) = Fusion device to communi-
cate with
All frames 'Fusion command' are sent to
this device
All frames 'Fusion answer' comes from
this device
Data(1..7) = Dummy 0xff
1794 0x702 Fusion command Passerelle NMEA2000 -
Fusion
Data(0) = Frame ID, if rst frame : 0x00
else counter
Data(1) = if frame ID=0 => nb data
bytes else data byte
Data(2..7) = Data bytes
Data byte description corresponds exac-
tly to Fusion protocol description.
Data byte(0) = 0xA3
Data byte(1) = 0x99
...
1795 0x703 Fusion answer Passerelle NMEA2000 -
Fusion
Data(0) = Frame ID, if rst frame : 0x00
else counter
Data(1) = if frame ID=0 => nb data
bytes else data byte
Data(2..7) = Data bytes
Data byte description corresponds exac-
tly to Fusion protocol description.
Data byte(0) = 0xA3
Data byte(1) = 0x99
...
