SCHEIBER
ISO 9001
SCHEIBER DIFFUSION
85120 SAINT PIERRE DU CHEMIN - FRANCE
Tél : 02 51 51 74 48 Fax : 02 51 51 99 50
Tél international : +33 2 51 51 74
48 Fax international : +33 2 51 51 99 50
E-mail: sav@scheiber.fr Site web: www.scheiber.fr
- 4 -
Date de mise à jour :11/08
INSTALLATION
Le chargeur doit être installé dans un lieu dégagé (environ 15 cm de chaque coté et 10cm sur le
dessus) et ne pas être recouvert.
Pour une meilleure ventilation naturelle, nous conseillons de fixer le chargeur verticalement.
Le chargeur est muni de cinq trous de fixations.
ABOUT THE CABLES
If cables have to be inserted through metal walls, use a cable duct or cable bushes.
Do not lay cables loose or with sharp bends on electrically conductive materials.
The specified minimum cable cross-section must be complied with (see chapter « cable section »).
Secure cables properly.
Lay cables in a way that they are not exposed to the risk of damage.
For disconnecting the device set the mains switch to « OFF » and unplug from the mains. It must
always be within hand reach.
When 230VAC supply wire is damaged, it must be replaced by our after sales department or by a
person having the required qualifications.
MAINTENANCE
BE CAREFUL :
If replacing a fuse, comply with the calibres given in the technical data. Any other value may
damage the charger.
Do not use the charger to charge some cells.
During the charge lead-batteries have to be in a well-ventilated location.
Only connect the charger in a main socket with earth.
You MUST connect the input clamp « earth » in a such way to ensure a continuity of people
protection by the differential of the plug on which the vehicle is connected (in case of bad insulation
of one of the equipment connected to the BIP 230VAC uses) ; for this purpose use the terminal
delivered with the accessories).
If cables are modified and cable-grips cut, once new wiring is finished you must change the cable-
grips.
Regularly check that connections are in good state (well screwed) otherwise it can entail an
overheating of the terminals
INSTALLATION AND PUTTING INTO OPERATION
The charger must be installed in a well-ventilated location (minimum 15 cm on each side and 10 cm
on the top) and must not be covered.
The charger has 4 fixing holes on the rear part.
The connection for the uses and for the battery on the charger is made by FASTON terminals.
