Schellenberg ROLLODRIVE 105 STANDARD User Manual

1716
GB
Only use original spare parts to avoid product malfunction or defects�
Improper running of the belt (belt guiding) may destroy the shutter belt and cause
unnecessary strain on the product� Install the product such that the belt enters the
shutter belt drive as vertically as possible� This will avoid unnecessary friction and
wear�
TECHNICAL DATA
Power supply unit operating
voltage
230 V / 50 Hz
Rated power 70 W
Standby power 0,5 W
Torque 14 Nm
Short-time operation 4 minutes
Max. speed 24 rpm
Enclosure rating IP 20 (for dry rooms only)
Protection class II
Number of switching times 2 (UP and DOWN)
Permissible ambient temperature 0-40 °C
Automatic solar control setting
range
2.000 through 20.000 Lux
Setting range automatic twilight
function
2 through 50 Lux
Dimensions see page 217
Permissible belt widths 23 mm (Maxi-belt)
Belt length 15 m with belt thickness of 1,0 mm
12 m with belt thickness of 1,3 mm
11 m with belt thickness of 1,5 mm
Max. shutter surface area 10 m
2
plastic
6,0 m
2
aluminium/wood
Max. roller shutter weight 4,5 kg/m
2
plastic
10 kg/m
2
aluminium/wood
Power cord 2x0,75 qmm H03VVH2-F
Number operating buttons 5
