Manufacturer
Scheppach
Fabrikation von Holzbearbeitungsmaschinen GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Dear customer,
We wish you much pleasure and success with your new
scheppach machine.
Note
In accordance with valid product liability laws, the manu-
facturer of this device shall not be responsible for damage
to and from this device which results from:
• Impropercare.
• NoncompliancewiththeOperatingInstructions.
• Repairsmadebyunauthorizedpersons.
• Theinstallationanduseofanypartswhicharenotorigi-
nal scheppach replacement parts.
• Improperuseandapplication.
• Failuretheelectricalsystemasaresultofnoncompli-
ance with the legal and applicable electrical directives
andVDEregulations0100,DIN57113/VDE0113.
We recommend
that you read through the entire operating instructions be-
fore putting into operation.
These operating instructions are to assist you in getting to
know your machine and utilize its proper applications.
The operating instructions contain important notes on how
you work with the machine safely, expertly, and economi-
cally, and how you can avoid hazards, save repair costs,
reduce downtime and increase the reliability and service
life of the machine.
In addition to the safety requirements contained in these
operating instructions, you must be careful to observe your
countryís applicable regulations.
The operating instructions must always be near the ma-
chine. Put them in a plastic folder to protect them from
dirt and humidity. They must be read by every operator
before beginning work and observed conscientiously. Only
persons who have been trained in the use of the machine
and have been informed of the various dangers may work
with the machine. The required minimum age must be ob-
served.
In addition to the safety requirements contained in these
operating instructions and your countryís applicable reg-
ulations, you should observe the generally recognized
technical rules concerning the operation of woodworking
machines.
General notes
• Afterunpacking,checkallpartsforanytransportdam-
age. Inform the supplier immediately of any faults.
• Latercomplaintscannotbeconsidered.
• Makesurethedeliveryiscomplete.
• Before puttinginto operation,familiarizeyourselfwith
the machine by carefully reading these instructions.
• Useonlyoriginalscheppachaccessories,wearingorre-
placement parts. You can find replacement parts at your
scheppach dealer.
• Whenordering,includeouritemnumberandthetype
and year of construction of the machine.
Basato 4
Lieferumfang
Bandsaw
Saw bench
Parallel guide rail
Operating instructions
Guide profile with adjustment knob
Adapter for suction
Push stick
Accessories bag
HexagonalwrenchSW10/13
Cross-section gauge
Transport handle
Base
OffsethexagonbarkeySW3/SW5
Technische Daten
Passage width mm
375
Passage height mm
250
Table size mm
400 x 548
Cutting speed m/min.
800/1200
Saw band length mm
2895
Saw band
width mm
6/30
Height up to tabletop
mm
1010
H x W x D mm
1800 x 643 x 1048
Slewing range of the
table°
-17°–+45°
Overall weight kg
108
Suction connection
ø mm
100
Band wheel ø mm
380
Antrieb
Motor V/Hz
230–240/50 400/50
Aufnahmeleistung
P1 kW
1,5 1,5
Abgabeleistung P2
kW
1,1 1,1
Betriebsart
S1 S1
Drehzahl
1500 1500
Motorschutz
yes yes
Unterspannungs-
auslösung
yes yes
Stecker
Schuko CEE
Subject to technical modifications!
m
In these operating instructions we have marked the
places that have to do with your safety with this sign.
m Safety notes
• Pleasepassonsafetynotesandinstructionstoallthose
who work on this machine.
Personnel entrusted with work on the machine must
have read the operating instructions and in particular
the chapter on safety before beginning work. Reading
the instructions after work has begun, is too late. This
applies especially to persons working only occasionally
on the rnachine, e.g. during setting up or rnaintenance.
• Observeallsafetyinstructionsandwarningsattachedto
the machine.
• Seetoitthatallsaftyinstructionsandwarningsattached
to the machine are complete and perfectly legible.
• Check all power supply lines. Do not use defective
lines.
• Make sure that the machine stands stable on rm
ground.
