• Pinchingwhenpowercordsareroutedthroughwindows
or door cracks.
• Bendingduetoimproperattachmentorroutingofthe
power cords.
• Cutsduetodrivingoverthepowercords.
• Insulationdamagecausedbyyankingthemainsplug
out of the power outlet.
• Cracksintheinsulationduetoageing.
Such faulty power cords must not be used and are a danger
to life because of the damaged insulation!
Inspect the power cords for damage on a regular basis.
Make sure that during this inspection the power cord is not
connected to the mains supply.
The power cords must comply with the applicable VDE
(German Association for Electrical, Electronic and In-
formation Technologies) and DIN (German Institute for
Standardization) regulations. Only use power cords marked
as H 07 RN.
A type identification printed on the power cords is pre-
scribed.
AC Motor
• Thepowersupplymustbe230–240V/50Hz.
• Extensioncordsmusthaveaminimumconductorcross
section of 1.0 square millimetres.
• Theconnectiontothepowersupplymustbeprotected
with a 16 A (delayed-action) fuse/ circuit breaker.
When you have questions, please include the following de-
tails:
• Motormanufacturer
• Typeofcurrent
• Thedetailsfromthetypeplateofthemachine
• Thedetailsfromthetypeplateoftheswitch
Always send back the whole drive unit including the switch,
when you return the motor.
appropriée des câbles électriques.
• Coupures
Fig. 5
Now plug the filter cartridge 1 onto the motor casing 2.
Place the entire motor casing on the container and secure
with the locking strap.
Mounting the exhaust hose, fig. 6 (earthing)
Remove the plastic sheathing from one end of the helix
flex, so that the blank lead A becomes visible (appr. 2
cm).
Fasten
theclamps(B)tothebarewire(A).
Mount exhaust hose C to the hose fitting on the casing us-
ing hose clamp D.
Fig. 7
Attach the other end of the exhaust hose using a hose
clamp and hose coupling E.
m Electrical Connection
Connecting the electrical equipment, or any repair work,
may only be carried out by a qualified electrician.
The built-in electric motor is already connected and ready
for operation. The connection conforms to the relevant
VDE (German Association for Electrical, Electronic and
Information Technologies) and DIN (German Institute for
Standardization) regulations.
The connection to the mains supply made by the custom-
er, as well as the extension cord used, must comply with
these regulations.
Important Notes
Faulty power cords
Power cords often suffer insulation damage.
Causes are:
