www.scheppach.com / service@scheppach.com / +(49)-08223-4002-99 / +(49)-08223-4002-58
GB
|
29
• Health hazard due to electrical power, with the use
of improper electrical connection cables.
• Furthermore, despite all precautions having been
met, some non-obvious residual risks may still re-
main.
• Residual risks can be minimised if the „safety in-
structions“ and the „Proper use“ are observed
along with the whole of the operating instructions.
• Do not load the machine unnecessarily: excessive
pressure when sawing will quickly damage the saw
blade, which results in reduced output of the ma-
chine in the processing and in cut precision.
• When cutting plastic material, please always use
clamps: the parts which should be cut must always
be xed between the clamps.
• Avoid accidental starting of the machine: the oper-
ating button may not be pressed when inserting the
plug in an outlet.
• Use the tool that is recommended in this manual.
In doing so, your machine provides optimal perfor-
mance.
• Hands may never enter the processing zone when
the machine is in operation.
• Release the handle button and switch o the ma-
chine prior to any operations.
Warning! This electric tool generates an electromag-
netic eld during operation. This eld can impair ac-
tive or passive medical implants under certain condi-
tions. In order to prevent the risk of serious or deadly
injuries, we recommend that persons with medical
implants consult with their physician and the manu-
facturer of the medical implant prior to operating the
electric tool.
6. Technical data
AC motor ....................................... 220−240 V~ 50Hz
Power S1 ....................................................2000 Watt
Idle speed n
0
..............................................4500 min
-1
Carbide saw blade .................... ø 255 x ø 30 x 3 mm
Number of teeth...................................................... 60
Maximum tooth width of saw blade ....................3 mm
Swivel range ....................................... −45° / 0°/ +45°
Mitre cut ............................... from 0° to 45° to the left
Saw width at 90° ................................... 340 x 90 mm
Saw width at 45°.....................................240 x 90 mm
Saw width at 2 x 45°
(double mitre cut) ...................................240 x 45 mm
Protection class ................................................... II /
Weight ....................................................... ca. 14,3 kg
Laser class ................................................................2
Wavelength of laser ........................................ 650 nm
Laser output ................................................... < 1 mW
The work piece must have a minimum height of
3 mm and a minimum width of 10 mm.
Make sure that the workpiece is always secured
with the clamping device.
Noise
Total noise values determined in accordance with EN
62841.
Sound pressure level L
pA
........................96.5 dB(A)
Uncertainty K
pA
..................................................3 dB
Sound power level L
WA
..........................109.5 dB(A)
Uncertainty K
WA
.................................................3 dB
Wear hearing protection.
The eects of noise can cause a loss of hearing
The above-mentioned noise emission values were
measured in accordance with a standardised test
procedure and can be used to compare one power
tool with another.
The above-mentioned noise emission values can
also be used for the preliminary assessment of ex-
posure.
Warning:
• The noise emissions during the actual use of the
power tool may dier from the above-mentioned
values depending on the power tool being used,
in particular on the type of workpiece being pro-
cessed.
• Try to keep emissions as low as possible. For ex-
ample: Limit your working time. In this regard, all
the operational cycle phases must be taken into
consideration (such as the times when the tool is
switched o or running idle).
7. Before starting the equipment
• Open the packaging and remove the device care-
fully.
• Remove the packaging material as well as the
packaging and transport bracing (if available).
• Check that the delivery is complete.
• Check the device and accessory parts for trans-
port damage.
• If possible, store the packaging until the warranty
period has expired.
DANGER
The device and packaging materials are not toys!
Children must not be allowed to play with plas-
tic bags, lm and small parts! There is a risk of
swallowing and suocation!
• The equipment must be set up where it can stand
securely. Secure the machine on a workbench or a
base frame with 4 screws (not included in delivery)
using the holes on the xed saw table (15).
