19 І 56
Perform all machine settings with the machine
being disconnected from the power supply!
Check before starting work:
• All cables and plugs
• The function of the protective cover (check the
spring!)
The sawing:
• Always use the proper, located in perfect condition
saw blades.
• If possible we recommend that the cutting depth is
set approximately 2 mm deeper than the material
thickness. This should help to ensure
• you achieve a clean cut.
• Do not exert too much pressure to the workpiece.
• Never lay up the saw with open protective cover.
Cutting depth (Fig.2)
• Lift the lock lever to release the cutting depth setting
clamp (7)
• Move indicator to the desired depth of cut
• Lower the lock lever to secure depth of cut
ON/OFF (Fig.3)
• Connect the plug to the power supply (230V):
The power on light (14) is on
• Push ON/OFF switch (5)
• Push the lock-off button (6) forward with the forenger
• The machine is running until releasing the ON/OFF-
switch
Enable cut (Fig.4)
• Let saw blade run to maximum speed
• Pressing the safety lock button (3) unlocks the plunge
cut mechanism at the same time, so that the motor
can be moved downwards
Guide fence (Fig.5)
• Release the lock screw for guide fence (11)
• Set the guide fence (B) in the guide fence slot (10)
• Set a desired width and retighten the lock screw for
the guide fence (11)
Laser (Fig.5)
• On/Off with switch (2)
• Line the laser up with cutting marks on your workpi-
ece
Dust extraction (Fig.7)
• Always use a dust extraction
• Plug the small end of the dust extraction hose (C) with
the dust collector plug (17)
• Connect the bigger end of C with a vacuum device
Selection of saw blades (Fig.8)
• Always use cutting tiles to the diamond wheel (D)
• Use of wood TCT saw blades always the (E).
• Always use plastic and Alumionium the HSS saw
blade (F)
Change the saw blade (Fig.9+10)
• Set cutting depth to maximum
• Press button and hold the spindle lock button (16)
• Use inner hexagon wrench to loosen and remove the
ange screw (8)
• Press the safety lock button (3) to lift up the base
plate (18)
• When cutting aluminium and plastics always use the
app ro priate clamps: all workpieces must be clamped
down rmly.
• Avoid accidental starts: do not press the start button
while inserting the plug into the socket.
• Always use the tools recommended in this manual
to obtain the best results from your plunge cut saw.
• Always keep hands away from the work area when
the ma chine is running; before performing tasks of
any kind release the main switch button located on the
handgrip, thus disconnecting the machine.
11. Technical Data
Dimensions L x W x H mm 410x100x135
Sawblade Ø mm 89
Idle Speed rpm 5500
Cutting depth mm 28.5
Weight kg 2.2
Motor V~/Hz 220-240 / 50
Input W 600
Protection Class II
Laser Class 2
Laser output ≤ 1 mW
Laser module power
supply
2 x LR44 button cell
Noise and vibration
Total vibration values determined in accordance with
EN 61029.
sound pressure level L
pA
86,33 dB(A)
uncertainty K
pA
3 dB
sound power level L
WA
97,33 dB(A)
uncertainty K
WA
3 dB
Vibrations sawing of wood a
h
2,533 m/s²
Vibrations sawing of metal a
h
2,845 m/s²
Vibrations sawing of concrete a
h
2,639 m/s²
uncertainty K 1,5 m/s
2
The work piece must have a minimum height of 3mm
and a minimum width of 10 mm.
Make sure that the workpiece is always secured with
the clamping device.
12. OPERATION
Operation instructions
Device to be operated in a perfect state only. Inspect
the device visually every time it is to be used. Check
in particular the safety equipment, electrical controls,
electric cables and screwed connection for damage
and if tightened properly. Replace any damaged parts
before operating the device.
