international 9
Legend, Fig. 1
Get to know your compressor:
Handle1
Pressure switch cover2
ON/OFF switch3
Tank pressure control4
Set button5
Adjustable drain valve6
Adjustable drain valve control7
Air tank8
Wheel (2x)9
Safety screen10
Oil filling plug11
Air filter unit12
Oil level sight glass13
Oil drain plug (not illustrated)14
Description of symbols
The model plate on your machine may show symbols. They
contain important information regarding the product or its
use:
Wear ear protection.s
Wear goggles.s
Wear a breathing mask.s
Meets the valid standards regarding electro-magnetic s
compatibility.
D General safety notes
Preserve these Operating Instructions well and have them
carefully read by every person working with the compressor.
Important information
Attentively read these Operating Instructions. Most of
the accidents when working with the compressor occur
through neglect of the basic safety rules. Recognizing po-
tential dangers in time and conscientious observance of
the safety instructions can avoid accidents. Only use the
compressor following the recommendations of the manu-
facturer.
D Safety notes
Do not touch moving machine parts.s
Do not use the compressor with the guards removed.s
Always wear goggles or another adequate eye protec-s
tion. Never point the compressed air current towards a
part of your body or towards another person.
Protection from electric shocks. Avoid inadvertent con-s
tact with the cables, the tank, or earthed metal parts
of the compressor. Never use the compressor close to
water or in a humid environment.
Pull the power supply plug before starting repair, in-s
spection, maintenance, or cleaning work, or before re-
placing any parts.
Inadvertent starting. Do not transport the compressor s
while it is connected to the electric power. Make sure
the switch is in OFF position before you plug in the
electric cable.
Store the compressor correctly. When the compressor s
is not used, it must be stored in a dry place protected
from weather conditions.
Working area. Make sure the work place is clean and s
well aerated. Put away any tools that are not needed.
