1 Bass Adjustment. (20Hz) Turning the knob
clockwise increases bass, turning it counter-
clockwise decreases bass. Like all the adjust-
ments on Loki, it has a gradual effect when
rst turned off of the center position, for subtle
adjustments.
2 Midbass Adjustment. (400Hz) As before, clock-
wise increases, counter-clockwise decreases.
3 Midrange Adjustment. (2kHz) You’ve got the
clockwise/counterclockwise thing now, right?
operation
1 2
4 Treble Adjustment (8kHz). Clockwise = more,
counterclockwise = less.
5 Bypass. Up = tone control active, down =
completely bypassed (only a relay and resistor in
the signal path.)
Note: when Loki is turned off it is technically
bypassed, but the unpowered input may cause
distortion in some systems. Best to turn it on
and switch it to bypass the tone controls.
3 4
5
