7 – MOUNTING OPTIONS
7.1 - WALL MOUNTING
Use the appropriate holes in the fixing tabs to screw n.2 screw #12 or M5
7.2 - DIN MOUNTING
1. Lift the DIN hook by pressing on the tab and pulling up
2. Hook the box to the DIN rail as follow:
a. Place the Cube on the DIN rail
1
2
