Schischek Redmax Series User Manual

EXPLOSIONPROOF
www.schischek.com
Schischek GmbH Germany, Muehlsteig 45, Gewerbegebiet Sued 5, 90579 Langenzenn, Tel. +49 9101 9081-0, Fax +49 9101 9081-77, E-Mail info-de@schischek.com
RedMax-M-F3_en
V01 – 19-Sep-2016
RedMax-...-F3 RedMax-...-SF3 RedMax-...-BF3
Special option ... -CTM
Technical data RedMax- 30 - F3 RedMax- 50 - F3 RedMax- ... - SF3 RedMax- ... - BF3
Approbations Special solutions and accessories
...-CTM Types in aluminium housing with seawater resistant coating,
parts nickel-plated
VAMH Casing in VA for ...Max actuators size M
RedBox-... Terminal boxes for zone 2, 22
MKK-M Mounting bracket for boxes type ...Box-... directly on actuator
ExPro-TT-... Safety temperature trigger for fire dampers
RedSwitch 2 external aux. switches, adjustable for zone 2, 22
AR-16-xx Reduction part for 16 mm square connection to 14 or 12 mm shafts
Kit-S8 Cable glands nickel-plated
Adaptions for dampers and valves on request
RedMax-...-S3 Ambient temperature up to +60 °C (T4), 110...240 VAC/DC, 25 % ED
Torque motor (min.) 30 Nm 50 Nm 30 resp. 50 Nm 30 resp. 50 Nm
Torque spring (F) min. 30 Nm min. 50 Nm min. 30 resp. 50 Nm min. 30 resp. 50 Nm
Dimension of external torque Above mentioned torques are min. torques in blocked position, external torque should be max. 80 % of max. actuator torque but min. 10 Nm
Supply voltage / frequency 24...240 VAC/DC, ± 10 %, self adaptable, frequency 50...60 Hz ± 20 %
Power consumption max. starting currents see
Extra information (in acc. with voltage, I
start
>> I
rated
), approx. 5 W holding power, approx. 16 W for heater
Protection class Class I (grounded)
Angle of rotation and indication 95° incl. ~ 5° pretension, mechanical value indication
Working direction Selectable by left/right mounting to the damper/valve shaft
Motor running times 40 / 60 / 90 / 120 / 150 s/90° selectable on site
Motor Brushless DC motor
Spring return (F) ≤ 3 s/90°, function in the event of loss of power resp. opening of line 3
Safety operation min. 1,000 in acc. with construction of damper and ambient
Response time spring return up to 1 sec. after power failure
Control mode On-off
Intrinsically safe circuit (type ...-BF3 only) – – – Ex-i circuit to connect the ExPro-TT-...
safety temperature trigger
IS connection (type ...-BF3 only) – – – directly to the actuator with M12 quick connection
Integrated aux. switches (type ...-SF3 and ...-BF3 only) – 2 aux. switches (5° and 85°) 2 aux. switches (5° and 85°)
Axle of the actuator Double square 16 × 16 mm, direct coupling, 100 % overload protected
Electrical connection Cable ~ 1 m, wire cross section 0.5 mm², equipotential bonding 4 mm².
Connections in hazardous areas require a terminal box!
Diameter of cable ~ Ø 7.0 mm ~ Ø 7.0 mm ~ Ø 7.0 + 7.6 mm ~ Ø 9.6 mm
2 cable glands in version ...-SF3
Cable gland M16 × 1.5 mm
Manual override Use delivered socket wrench, max. 4 Nm
Integral heater Integral, controlled heater for ambient temperature down to −40 °C
Housing material Aluminium die-cast housing, coated. Optional with seawater resistant coating (...-CTM)
Dimensions (L × W × H) 288 × 149 × 116 mm, for diagrams see
Extra information
Weight ~ 9.5 kg aluminium housing
Ambients Storage temperature −40…+70 °C, working temperature −40…+40 °C at T6 and −40…+50 °C at T5
Humidity 0...90 % rH, non condensing
Operation mode 100 % ED are permitted (ED = duty cycle)
Maintenance Maintenance free relative to function, maintenance must comply with regional standards, rules and regulations
Wiring diagrams SB 2.4 + 2.5 SB 2.4 + 2.5 SB 2.4 + 2.5 + 3.2 SB 2.4 + 2.5 + 3.2 + 7.4
Scope of delivery Actuator with 1 m cable, 4 screws M8 × 140 mm, 4 nuts M8, Allen key for simple manual override
Parameter at delivery 30 Nm, 90 s/90° 50 Nm, 90 s/90° 30 resp. 50 Nm, 90 s/90° 30 resp. 50 Nm, 90 s/90°
ATEX directive 2014/34/EU
EC type-approved PTB 04 ATEX 2106
IECEx certified IECEx PTB 08.0059
Approval for gas II 3 (1) G Ex nC [ia] IIC T6, T5
II 3 G Ex nC II T6, T5
Approval for dust II 3 D Ex tD A22 IP66 T80, T95°C
Ex-i circuit data see table (T 1.0)
CE identification CE № 0158
EMC directive 2014/30/EU
Low voltage directive 2014/35/EU
Enclosure protection IP66 in acc. with EN 60529
EAC № ТС RU С-DE.ГБ08.В.01510
Gas 2Ex nC IIC T6/T5 Gc X / 2Ex nC [ia Ga] IIC T6/T5 Gc X
Dust Ex tD A22 IP66 T80°C/T95°C / Ex tD[iaD] A22 IP66 T80°C/T95°C
2 / 4
