SCHLAGEL, INC. SCHLAGEL, INC.
EDI - V5 CONTROL
Figure 1 General wiring layout
Schlagel, Inc.
491 N. Emerson, Cambridge MN 55008
763-689-5991, 800-328-8002 Fax 763-689-5310
sales@schlagel.com, www.schlagel.com
Failure to comply with the wiring instructions in this document could lead to improper operation,
equipment damage or serious injury or death.
The EDI control should only be installed and wired by experienced electricians. Make sure the wiring
meets all applicable regulations and codes including local and national standards and codes.
High voltage can
kill or seriously injure personnel. All maintenance personnel must be trained and
follow the proper Lockout/Tagout procedures established by the facility management.
Fwd-Rev
Switches
Inverter Drive
To Next Page
