•Quadrature Sine Wave VCO / State Variable Filter
-with four phase related outputs: 0°, 90°, 180°, 270°
-or lter response outputs: LOW PASS, BAND PASS, HIGH PASS, INVERTED BAND PASS
•HIGH range from 10Hz to over 20kHz
•LOW range from 0.3Hz to over 600Hz
•Sine wave outputs are 5Vpp (+-2.5V)
•Grind section is a voltage controlled waveshaping section
-or pole mixing nonlinear feedback network
-GRIND and lter outputs are not limited and can hit 22Vpp (+-11V)
•Tracks 4+ octaves of volts per octave at the V/OCT input
•FM1 is selectable linear or exponential FM via jumper on back
•FM2 is additional exponential V/OCT jack
•Grind section is a voltage controlled waveshaping section
-or pole mixing nonlinear feedback network
-GRIND CV inputs are unipolar 0 - 5V with bias from sliders
•The INJECT jack can be used as a second input for either audio or CV, bypassing GRIND
•All analog OTA based design
•18 HP
•Power requirements :+12V 81mA, -12V 78mA
Please address questions or issues to: eric@schlappiengineering.com
SPECIFICATIONS
SCHLAPPI ENGINEERING
