Installation manual FlatGrid | 2020.03 V.001
Schletter Solar GmbH – Alustraße 1 – 83527 Kirchdorf, Germany
FlatGrid
Installation manual
Tools needed
Tape measure
Screwdriver with bit socket,
SW6 Allen screw bit
Torx T40 bit
Other documents needed
General assembly instructions –
Assembly and project planning
FlatGrid product sheet
Tightening torques
M8 screw connections: 15 Nm
