Installation manual FlatGrid | 2020.03 V.001
Schletter Solar GmbH – Alustraße 1 – 83527 Kirchdorf, Germany
Safety instructions
Installation instructions
The system is to be installed only with ballasting according to the design documents. You can get these from us with our system design, or directly
through software in the download area at www.schletter-group.com .
Breakage hazard! PV modules can be damaged if they are stepped on.
Planning of the photovoltaic system, installation and commissioning may be done only by qualified technical personnel. Improper installation can cause
damage to the system and endanger people.
Electrical hazard! Installation and maintenance of the photovoltaic system is to be done only by qualified technical personnel. Observe the safety
regulations of the PV module manufacturer!
Falling hazard! There is a risk of falling when working on the roof and when climbing up and down. Is it imperative that the accident prevention
regulations be observed and that suitable fall protection devices be used.
Injury hazard! People may be injured by falling objects. Before starting the installation, block off any danger zones and warn people nearby!
For very uneven roofs or roofing strips, compensation measures may be needed to ensure even application of the load.
Necessary distances to roof edges must be maintained.
Due to linear thermal expansion, the main beams must be separated by reasonable distances. A recommended reference value for the maximum bar
length on foil roofs is 10 m.
FlatGrid is not recommended for roofs with more than a 10-degree slope. For slopes of 3° and more, additional fastening may be needed on the roof.
The surface load must not exceed the building’s residual load capacity!
For static reasons, at least two contiguous rows of modules must be installed. If this is not possible, please contact Technical Advice.
Please follow any project-related instructions in the planning documentation!
