schmersal PSC1-C-10-MC User Manual

Installation manual
HB-37350-810-01-50F-EN PSC1-C-10 Installation manual V2.1.docx Page 186 of 189
Version: 50F
Two-handed operation
Switch type
Remark
Category
categorisation
SIL categorisation
2 change-over
contacts
Two-hand button for
increased requirement
Type III C PL e
SIL3
2 normally open
contacts
Monitored two-hand button
Type III A PL c
SIL1
Note:
On these input elements there is a fixed pulse assignment that the user cannot change!
Light curtain
Switch type
Remark
Category
categorisation
SIL categorisation
2 normally closed
contact
Light curtain for increased
requirement
PL e
SIL 3
2 normally closed
contacts time
monitoring
Monitored light curtain
PL e
SIL 3
1 normally open
contact + 1 normally
closed contact
Light curtain for increased
requirement
PL e
SIL 3
1 normally open
contact + 1 normally
closed contact time
monitored
Monitored light curtain
PL e
SIL 3
Operating mode selector switch
Switch type
Remark
Category
categorisation
SIL categorisation
2 positions
Monitored operating mode
selector switch
PL e
SIL 3
3 positions
Monitored operating mode
selector switch
PL e
SIL 3
Safety instructions:
 On a state change on the switch, it is to be ensured by the SafePLC2 program to be
written that the outputs on the module are deactivated
Sensor
Switch type
Remark
Category
categorisation
SIL categorisation
1 normally closed
contact
Simple sensor input
PL d
SIL 2
1 normally open
contact
Simple sensor input
PL d
SIL 2
2 normally closed
contact
Sensor input for increased
requirement
PL e
SIL 3
2 normally closed
contacts time
monitoring
Monitored sensor input
PL e
SIL 3
