68 Copyright © 2020 Axxiom Manufacturing, Inc.
A) Pneumatic and Electric Fan Motor Systems (see note below & see Section 9.0 drawings)
ITEM
QTY
PART # DESCRIPTION
1 & 2
5
4211-999 Crowfoot gasket (may not apply to some systems)
3
2
2401-502 Pre-filter/After-filter drain ball valve, 1/4" (ACS/ADS 400-2500 systems)
7
2
7000-001-18 Handway gasket, 6” x 8” SureFit™ (only for ADS 400-2500 systems)
8
2
7064-009 Sight glass, 2” (only for ADS systems)
9
1
1310-000-03 Deliquescent tablets (ADS Systems only; see Section 2.2 for capacity)
11
1
2401-50X Separator tank drain ball valve, full port
20
1
4102-10X-XXX Air hose assembly (250P/400P portable systems)
21
10
7119-002 Safety pin, air/blast hose coupling
22
2
8710-98778 Hose whip safety check (safety cable)
24
1
7031-999-XX Safety decal kit
B) Items for Pneumatic Fan Motors Systems Only (see note below)
ITEM
QTY
PART # DESCRIPTION
5
1
1300-XXX-03 Air motor
5
2
1300-XXX-99 Air motor replacement parts kit
13
1
2401-504 Air motor shutoff ball valve, 1/2" full port
14
1
2312-X04-99 Air filter/regulator repair kit
14
1
2309-X04-99 Air filter/regulator repair kit (systems manufactured prior to Sept. 2016)
15
1
2311-X04-99 Air lubricator repair kit
15
1
2304-X04-99 Air lubricator repair kit (systems manufactured prior to Sept. 2016)
16
1
2010-009-01 Pressure gauge, 0-160 psi
17
1
2011-XXX-01 Air motor muffler
C) Items for Electric Fan Motors Systems Only (see note below)
ITEM QTY PART # DESCRIPTION
6
1
1300-XXX-XX Electric fan/motor assembly (250P/400P portable systems)
6
1
1300-XXX-XX Electric motor (specify system size and voltage) (400-2500 systems)
18
1
7135-XXX Electric motor starter (specify size/voltage) (400-2500 systems)
18
3
7135-XXX Motor starter thermal unit (specify size/voltage) (400-2500 systems)
NOTE: Determine the type of radiator fan motor on the AirPrep System (either electric or
pneumatic). Then, the required list of spare parts is List “A” plus either List “B” or “C”. Example: If
your AirPrep System has pneumatic fan motor then the recommended spare parts you need are those
items included in Lists “A” and “C”.
10.0 Recommended Spare Parts Lists
