Page 9
5. Installation | Adjusting the doors by sliding the frame on the bottom adapter
It may be necessary to slide all lower profiles in one or in the other direction to be able to adjust the level of the doors.
If the sliding of the frames does not allow a perfect adjustement, make an average adjustment that can be refined later.
If the doors do not close themselves pull the frame slightly out.
Important remark: For a proper door closing the door must lean slightly inside the cabinet. Assure this during the
adjustment procedure.
If the doors are not aligned in the internal/external direction, push slightly one corner of the frame in and pull the other
corner out
Once the doors are adjusted and closing automatically via gravity,
fix the frame with 3 Alu rivets (Ø4,8x25) which are put through the
foreseen holes in the frame.
Close the bottom part with the delivered cover
once the rivets are in place
5–10mm at
a height of
1800mm
